High uniformity, excellent straightness, wide wavelength & fan angle selection. The Uniform Line Laser delivers exceptional beam uniformity and straightness for precision alignment and machine vision applications. With a wide wavelength range from 405 to 980 nm and selectable fan angles, this compact laser module provides reliable, high-performance line projection for industrial integration. - Wavelength: 405-980 nm with output power from 10 to 200 mW - Fan angle options: 15°, 30°, 45°, 60°, 75°, 90°, and 110° - Line uniformity ≥ 80% with straightness of 0.05% and working distance up to 2000 mm - Input voltage: 5-24 Vdc with CW, TTL, or analog modulation; service life up to 15,000 hours

Telecentric design, 10–5000mm WD, <0.05% straightness, high uniformity & Gaussian. OEM/wholesale. This Telecentric Uniform Line Laser delivers exceptional beam uniformity and straightness for precision machine vision and industrial alignment applications. Engineered with a telecentric optical design, it ensures consistent line thickness and high Gaussian uniformity across a wide working distance range, making it ideal for OEM integration and wholesale supply. - Wavelength: 405–980nm | Power: 30–2000mW | Power Stability: 5% - Working Distance: 10–5000mm | Line Straightness: 0.05% | Line Uniformity: ≥85% - Fan Angle: 15°, 30°, 45°, 60°, 75° | Line Thickness (1/e²): 10–2000μm - Input Voltage: 5–24V DC | TTL Modulation: 0V Off, 3.3V On | MTTF: 15,000 hours

455/525/638nm, 2.5–80W, FC/SMA905/ST. OEM/wholesale

Low noise (<0.1% RMS), high polarization ratio >100:1, warm-up <1min.

4000–7000K color temp, ACC control, stable output, ideal for 3D & laser display, low MOQ. The RGB Fiber Laser delivers stable, high-precision multi-wavelength output with ACC control and a wide color temperature range, making it ideal for advanced 3D laser display and industrial processing applications. - Wavelengths: 638nm, 525nm, 450nm with fiber output power options from 3W to 16W - Color temperature adjustable from 4000K to 7000K with temperature coefficient of 0.3 - Fiber core: 4/124μm (single-mode) or 49/125μm (multi-mode), NA 0.12, connector options SMA905/FC/ST - Operating temperature: 10-35°C, storage: 10-60°C, low MOQ available

Compact sizes (Ø3.3–12mm), 635–685nm, OEM/wholesale   Compact Red Laser Modules from Ø3.3mm to 12mm offer versatile dot, line, and cross-line patterns for OEM and wholesale applications. These industrial-grade modules deliver stable output across 635-685nm wavelengths with APC/ACC and CW operating modes. - Available in 12 compact sizes (Ø3.3x9mm to Ø12x40mm) with dot, line, or cross-line patterns - Output power ranges from 0.5mW to 200mW across 635nm, 650nm, 660nm, 670nm, and 685nm wavelengths - Operating voltage options: 3V or 5V DC with APC+CW, APC/ACC+CW, or APC/ACC+PWM modes - Ideal for industrial alignment, positioning, and visual indication systems requiring 660 nm red light

635nm, 650nm,660nm, 670nm, 685nm, 5–2400mW, single & multi-mode, Ø5.6/Ø9mm. High-performance Red Laser Diodes delivering precise visible light output from 635nm to 685nm, with power ranging from 5mW to 2400mW. Ideal for industrial alignment, medical equipment, and scientific instrumentation, these diodes offer reliable single-mode or multi-mode operation in compact Ø5.6mm and Ø9mm packages. - Wavelength options: 635nm, 650nm, 660nm, 670nm, 685nm for versatile red light applications - Output power: 5mW to 2400mW, supporting both low-power and high-power requirements - Package diameters: Ø5.6mm and Ø9mm, with single-mode and multi-mode configurations - Operating temperature range: -10°C to +85°C, ensuring stable performance in demanding environments

High-precision Powell lens, ultra-straight line, low intensity ripple, excellent line uniformity, OEM/ODM   The Powell Line Lens is a high-precision optical component engineered to generate ultra-straight laser lines with exceptional uniformity. It minimizes intensity ripple and ensures consistent line quality, making it ideal for machine vision, 3D scanning, and alignment applications. Available with OEM/ODM customization to meet specific project requirements. - Available in Ø6mm and Ø9mm diameters with fan angles from 15° to 110° - Supports input beam sizes (1/e²) from 0.8mm to 5mm with line straightness as low as 0.1% - Line intensity variation maintained within 20% for superior uniformity - Customizable part numbers and specifications for OEM/ODM integration

High precision, efficient, with protection features, ideal for portable laser devices. This high-precision Laser Driver IC series delivers programmable, efficient current control for portable and industrial laser diode applications, integrating essential protection features such as thermal shutdown, soft-start, and reverse polarity protection. Designed for both common cathode and common anode configurations, these drivers support APC and ACC operating modes with expandable current capabilities via external power transistors. - FX6003: APC mode, 20mA–150mA programmable current, thermal shutdown, soft-start, SOT23-6 package - FX6006: APC/ACC dual mode, 2mA–500mA programmable current, soft-start, DFN8 (2×2) package - FX6017: Common cathode APC, 200mA internal drive, expandable with external transistor, reverse polarity protection, DFN8 (2×2) - FX6103: Common anode ACC, 10mA–250mA adjustable current, reverse voltage protection, soft-start, SOT23-6 - FX6110: Common anode ACC, 1A internal drive, expandable with external transistor, programmable current, reference voltage output, DFN8 (2×3)

Indoor dry fire training, 5–100 yds range, Class II safe. OEM/wholesale.

Multiple connectors & core sizes, stable output, OEM/ODM ready.   The MXTLASER Integrated Fiber Laser offers a versatile, high-stability solution for applications spanning industrial, medical, and biochemical fields. This OEM/ODM-ready system supports a wide range of wavelengths from deep ultraviolet to infrared, with customizable fiber optic probes and connectors to meet exact project requirements. - Wavelength range: 395-1550nm (Red, Violet/Blue, Green, Infrared) with output power from 5 to 2000mW - Fiber core diameters: 9, 62.5, 105, 200, 600µm with connector options: FC, SMA905, ST - Customizable design: fiber length, connector type, power supply (CW, TTL, Analog), and voltage (1.5-24V DC) - Rapid prototyping: single prototypes and small production runs available for custom specifications

Ø3.3–12mm, 780–980nm, ideal for night vision & sensing. OEM/wholesale.   This compact Infrared Laser Module series delivers high-performance near-infrared output from 780nm to 980nm, engineered for precision night vision sensing and industrial alignment. Available in diameters from Ø3.3mm to Ø12mm, these modules offer versatile dot, line, and cross-line patterns with stable APC/ACC and CW operating modes. - Wavelength options: 780nm, 808nm, 830nm, 850nm, 905nm, 940nm, and 980nm - Output power range: 0.5mW to 200mW, supporting dot, line, and cross-line patterns - Operating voltage: 3V or 5V DC with APC, ACC, CW, and PWM modes - Ideal for OEM/wholesale applications in night vision sensing, machine vision, and laser alignment

780–1550nm, 5mW–12W, single & multi-mode, Ø5.6/Ø9mm. OEM/wholesale. 780nm, 808nm, 830nm, 850nm, 905nm, 980nm, 1064nm, 1310nm, 1550nm laser diodes High-performance Infrared Laser Diodes covering a broad wavelength range from 780nm to 1550nm, with output power from 5mW to 12W. Available in both single-mode and multi-mode configurations, these diodes are designed for diverse OEM and wholesale applications requiring reliable, high-quality laser sources. - Wavelength options: 780nm, 808nm, 830nm, 850nm, 905nm, 940nm, 980nm, 1064nm, 1310nm, and 1550nm - Output power range: 5mW to 12W, supporting low to high-power applications - Package diameters: Ø5.6mm and Ø9mm, with both single-mode and multi-mode models - Wide operating temperature range: -40°C to +70°C, suitable for industrial and commercial use

Focusable or fixed, multi-size, multi-wavelength, Rugged industrial design. OEM/wholesale. This Industrial Laser Module offers a versatile and rugged solution for demanding OEM and wholesale applications, featuring multiple sizes, wavelengths, and focus options. Designed for precision alignment, marking, and measurement, it delivers reliable performance across various industrial environments. - Available in Ø20x90mm (focusable with lock ring), Ø22x100mm (fixed focus), and 40x40x78mm (focusable with cooling fan) sizes - Supports multiple laser patterns: Dot, Line, Cross, and DOE, with output power ranging from 5mW to 2500mW - Offers a wide wavelength selection from 405nm Violet to 980nm Infrared, including Blue, Green, Red, and Invisible IR - Operates on 5V or 12V DC, with rugged industrial design suitable for OEM/wholesale supply

Ø3.3–12mm, 505–520nm, stable, high-brightness output, OEM/wholesale. This compact Green Laser Module series delivers stable, high-brightness output across a wide range of sizes and power levels, ideal for OEM integration and wholesale applications. Designed for precision alignment and industrial use, these modules offer versatile laser patterns and reliable performance. - Available in diameters from Ø3.3mm to Ø12mm with dot, line, and cross line patterns - Wavelength options: 505nm and 520nm, with output power ranging from 0.5mW to 80mW - Operating voltage: 3V/5V or 5.8~7V DC, with APC, ACC, and CW operating modes - Suitable for OEM, wholesale, and adjustable focus applications as a compact green laser alignment tool

Single-mode,505nm, 520nm,532nm, 10–135mW, Ø5.6/Ø3.8mm. OEM/wholesale. High-performance single-mode green laser diodes delivering stable 520nm wavelength output from 10mW to 135mW, ideal for OEM integration and wholesale supply. These compact laser diodes offer reliable operation across a wide temperature range, ensuring consistent performance in demanding industrial and scientific applications. - Wavelength: 520nm (single-mode), with options for 505nm and 532nm - Output Power: 10mW to 135mW, available in multiple power grades - Package Diameter: Ø5.6mm and Ø3.8mm for flexible integration - Operating Temperature: -10°C to +70°C, with OEM/wholesale support

Adjustable power, high uniformity, fast response, high stability, efficiency >95%, ideal for crime scene.

Rugged & reliable dual laser sight, low divergence, long MTTF. OEM/wholesale.

Adjustable focus with locking ring, APC/ACC driver. High quality glass optics, stable pattern output The DOE Laser is a high-precision diffractive optical element module designed for stable and repeatable pattern projection in industrial and medical applications. Featuring an adjustable focus with a locking ring and advanced APC/ACC driver circuitry, it ensures consistent output power and pattern clarity across varying conditions. - Compact Φ20*90mm housing with DOE pattern output - Wide operating voltage range: 3V-24V DC - Adjustable focal length with locking ring for precise beam control - Output power: 5-200mW; Wavelength: 405-980nm - Ideal for industrial equipment, medical treatment, and laser marking

Line arrays, dot grids, crosshairs, circles, ideal for 3D & alignment. OEM/wholesale. Precision-engineered Diffractive Optical Elements (DOEs) for generating line arrays, dot grids, crosshairs, and circles, specifically designed for high-accuracy 3D alignment and machine vision applications. These elements offer customizable pattern geometries and are available for OEM and wholesale supply. - Available patterns include single and multi-line arrays (square/rectangular), dot grids, crosshairs, and viewfinders with circles - Design wavelengths range from 450 nm to 660 nm, with optimum performance across 425–750 nm - Pattern sizes and angles are specified at a 100 mm distance, with typical projection angles from 5° to 67° - Ideal for industrial alignment, laser positioning, and optical metrology systems
