Laser Diode Module
635nm 638nm 650nm and 660nm 660nm 670nm 685nm Dot /Line/Cross Line
The advantages of red laser module are cost efficiency, low driving voltage and power consumption, and smaller dimension size.The major wavelengths of red laser modules are 635nm,638nm, 650nm, and 660nm,660nm,670nm,685nm laser diode module usually applied to Electronics, aiming, industrial equipment.
Note:
For mass production purchases over USD 1.000. please contact us.
The estimated lead time is from 8 to 20 business days depending on the available stocks. For detailed lead times, please contact us.
Related Products
-
Ø3.3–12mm, 505–520nm, stable, high-brightness output, OEM/wholesale.
This compact Green Laser Module series delivers stable, high-brightness output across a wide range of sizes and power levels, ideal for OEM integration and wholesale applications. Designed for precision alignment and industrial use, these modules offer versatile laser patterns and reliable performance.
- Available in diameters from Ø3.3mm to Ø12mm with dot, line, and cross line patterns
- Wavelength options: 505nm and 520nm, with output power ranging from 0.5mW to 80mW
- Operating voltage: 3V/5V or 5.8~7V DC, with APC, ACC, and CW operating modes
- Suitable for OEM, wholesale, and adjustable focus applications as a compact green laser alignment tool -
Telecentric design, 10–5000mm WD, <0.05% straightness, high uniformity & Gaussian. OEM/wholesale.This Telecentric Uniform Line Laser delivers exceptional beam uniformity and straightness for precision machine vision and industrial alignment applications. Engineered with a telecentric optical design, it ensures consistent line thickness and high Gaussian uniformity across a wide working distance range, making it ideal for OEM integration and wholesale supply.
- Wavelength: 405–980nm | Power: 30–2000mW | Power Stability: 5%
- Working Distance: 10–5000mm | Line Straightness: 0.05% | Line Uniformity: ≥85%
- Fan Angle: 15°, 30°, 45°, 60°, 75° | Line Thickness (1/e²): 10–2000μm
- Input Voltage: 5–24V DC | TTL Modulation: 0V Off, 3.3V On | MTTF: 15,000 hours -
Focusable or fixed, multi-size, multi-wavelength, Rugged industrial design. OEM/wholesale.This Industrial Laser Module offers a versatile and rugged solution for demanding OEM and wholesale applications, featuring multiple sizes, wavelengths, and focus options. Designed for precision alignment, marking, and measurement, it delivers reliable performance across various industrial environments.
- Available in Ø20x90mm (focusable with lock ring), Ø22x100mm (fixed focus), and 40x40x78mm (focusable with cooling fan) sizes
- Supports multiple laser patterns: Dot, Line, Cross, and DOE, with output power ranging from 5mW to 2500mW
- Offers a wide wavelength selection from 405nm Violet to 980nm Infrared, including Blue, Green, Red, and Invisible IR
- Operates on 5V or 12V DC, with rugged industrial design suitable for OEM/wholesale supply -
Compact sizes (Ø3.3–12mm), 635–685nm, OEM/wholesaleCompact Red Laser Modules from Ø3.3mm to 12mm offer versatile dot, line, and cross-line patterns for OEM and wholesale applications. These industrial-grade modules deliver stable output across 635-685nm wavelengths with APC/ACC and CW operating modes.
- Available in 12 compact sizes (Ø3.3x9mm to Ø12x40mm) with dot, line, or cross-line patterns
- Output power ranges from 0.5mW to 200mW across 635nm, 650nm, 660nm, 670nm, and 685nm wavelengths
- Operating voltage options: 3V or 5V DC with APC+CW, APC/ACC+CW, or APC/ACC+PWM modes
- Ideal for industrial alignment, positioning, and visual indication systems requiring 660 nm red light
